DVI Video Splitter

Use One DVI-Enabled PC to Display the Same High-Resolution Image on Two Monitors.

Also known as: DVI splitter, video splitter, DVI video splitters, video distribution amplifier,
PC video splitter, monitor splitter, multiple monitor, video port expander, LCD Y splitters.

Additional Product Information

View Data Sheet Data Sheet (PDF)
 VOPEX-DVI-2
VOPEX-DVI-2 (Front & Back)		 RoHS Compliant DVI Video Splitter

Features & Applications

The DVI video splitter enables two DVI-D displays (monitors, HDTV (LCD, PDP), projectors) to be driven by a single digital DVI source (PC, DVD player, Satellite receiver) with no loss of signal. DVI output-1 is the primary connection and is used for the main display. DVI output-2 follows the main display.
  • Ideal for presentations.
  • Connects HDTV or computer DVI source to multiple DVI compatible displays or projectors.
  • Provides high digital resolution up to 1920x1200.
  • Distributes digital DVI graphic signal to two displays simultaneously.
  • No distortion or attenuation of the signal.
  • Supports DDWG standard for DVI compliant monitors.
  • Full DDC2B communications are supported on Output-1.

Specifications

Hosts

  • Compatible with computers and HDTV video sources (satellite receivers, DVD players, etc) with DVI-D outputs.
  • Female DVI-I connector.

Monitor

  • Two female DVI-I connectors.
  • Actual bandwidth: 1.6 GHz.
  • Video bandwidth: 165 MHz.
  • Supports 480i, 480p, 720i, 720p and 1080i resolution for HDTV displays.
  • Supports up to 1920x1200 resolution for monitors.
  • Full DDC2B communications are supported on Output-1.

Power

  • 110 or 220 VAC at 50 or 60 Hz via AC adapter.
  • Power consumption: 5W

Dimensions

  • WxDxH (mm): 178x107x28.
  • Weight: 1kg.

Cables

  • Includes 0.9 meter male DVI-I to male DVI-I cable (DVI-IS-3-MM).

Environmental

  • Operating temperature: 0°C to 40°C (32°F to 104°F).
  • Storage temperature: -10°C to 70°C (14°F to 158°F).

Regulatory Approvals

  • CE, FCC, RoHS

Warranty

  • Two years
VOPEX-DVI-2 Application Drawing

DVI Video Splitter

NTI Part #Description
VOPEX-DVI-22-port DVI video splitter
Compatible DVI-D Male to Female
Dual Link Extension Cable
Part # Length (m)
DVI-D-3 0.9
DVI-D-6 1.8
DVI-D-9 2.7
